Astria Montecito-B High-Efficiency Wood Burning Fireplace (Monte-B) #Monte-B

Astria Montecito-B High-Efficiency Wood Burning Fireplace (Monte-B)


Item#: Monte-B

Price: $0.00


Order Now

Catalog No. F4481

MAIN ASSEMBLY

Item Description (Part Number)

QTY: 1 Blower Kit [Heat Activated On/Off Pre-Wired] (F3544) +$354.40

QTY: 2 Blower Motor Speed Control [Wall Mount] (VRUW) +$274.67

QTY: 3 Blower Snap Disc (VTU) +$239.07

QTY: 4 Baffle Refractory [set of 2] (PR-ISO2205) +$572.34

QTY: 5 Back Refractory (PR-SR2618) +$743.35

QTY: 6 Right Side Refractory (PR-SR2619D) +$743.35

QTY: 7 Left Side Refractory (PR-SR2619G) +$743.35

QTY: 8 Bottom Refractory (PR-SR2201) +$743.35

QTY: 9 Right Side Front Refractory (PR-SR2202D) +$743.35

QTY: 10 Left Side Front Refractory (PR-SR2202G) +$743.35

QTY: 11 Door Handle [set of 2] (PR-SR1787) +$206.85

QTY: 12 Door Rod and Lock (PR-SR2118) +$160.79

QTY: 13 Fireplace Door and Hinge (PR-SR2395TCE) +$148.93

QTY: 14 Black Decorative Screw & Cap [includes 8 screws, 16 caps] (PR-SACMEFBK) +$201.77

QTY: 15 Brushed Nickel Decorative Screw & Cap [includes 8 screws, 16 caps] (PR-SACMEFBN) +$249.24

QTY: 16 Ceramic Glass Panel (PR-SR2222-1) +$988.26

QTY: 17 Secondary Air Tube (PR-SR2271) +$160.79

QTY: 18 Cast-Iron Log Retainer Support [2 per unit, each sold separartely] (PR-SR2324) +$178.03

QTY: 19 Cast Iron Log Retainer Bar (PR-SR2323) +$171.25

QTY: 20 Glass Gasket for Steel and Cast Door (PR-SR1823H) +$92.65

QTY: 21 Steel Door Frame Gasket (PR-SR1685D) +$101.50

QTY: 22 Cast Door Frame Gasket (PR-SR1823G) +$159.44

QTY: 23 Black Metallic Touch-Up Paint (H8159) +$65.99

QTY: 24 Charcoal Touch-Up Paint [For Hammered Finish] (PR-P6201) +$101.50

QTY: 25 Outside Air Coupler (UZIAD) +$74.00

QTY: 26 Coupler for AC Chimney (H3274) *No Longer Available* +$*0.00*

QTY: 27 Blower for Central Forced Air Kit (BISZY) +$699.61

QTY: 28 Blower to Flexible Pipe Adapter (BISAVF) +$182.99

QTY: 29 Backdraft Damper (BISBD) +$76.06

QTY: 30 Flex Adapter with 2 Clamps (BISAF) +$174.71

QTY: 31 Metal Fab Collar and Sleeve (F4189) +$Call to Order

QTY: 32 Top Standoff Header Shield (F4713) +$244.15

QTY: 33 Damper Rod (H8393) +$183.12

CHIMNEY COMPONENTS

Item Description (Part Number)

QTY: 34 6 Inch Stainless Steel Chimney Length [set of 2] (F3966) +$342.00

QTY: 35 12 Inch Stainless Steel Chimney Length [set of 2] (F3967) +$363.00

QTY: 36 18 Inch Stainless Steel Chimney Length [set of 2] (F3968) +$395.00

QTY: 37 24 Inch Stainless Steel Chimney Length (F3969) +$224.00

QTY: 38 36 Inch Stainless Steel Chimney Length (F3970) +$235.00

QTY: 39 48 Inch Stainless Steel Chimney Length (F3971) +$267.00

QTY: 40 15 Degree Stainless Steel Elbow [set of 2] (F3972) +$438.00

QTY: 41 30 Degree Stainless Steel Elbow [set of 2] (F3973) +$438.00

QTY: 42 Firestop Spacer (F3974) +$32.00

QTY: 43 Insulation Shield (F3975) +$128.00

QTY: 44 Flat Flashing (F3976) +$106.00

QTY: 45 2/12-5/12 Flashing (F3977) +$106.00

QTY: 46 6/12-10/12 Flashing (F3978) +$171.00

QTY: 47 Roof Brace (F3980) +$128.00

QTY: 48 Storm Collar (F3981) +$32.00

QTY: 49 Round Cap with Spark Arrester (F3982) +$139.00

QTY: 50 Non-Insulated Wall Firestop (F3983) +$106.00

QTY: 51 Adjustable Support (F3984) +$74.00

QTY: 52 Wall Band (F3985) +$64.00

QTY: 53 Support Band (F3986) +$32.00

ACCESSORIES

Item Description (Part Number)

QTY: 54 Black Montecito Facade (F2320) +$917.27

QTY: 55 Hammered Steel Montecito Facade (F3609) +$2460.00

QTY: 56 Black Montecito Door (F1857) +$1149.00

QTY: 57 Hammered Steel Montecito Door (F3610) +$2460.00

QTY: 58 Black Cast Iron Door (F1859) +$1283.00

QTY: 59 Outside Air Coupler to Connect Outside Air to Fireplace (UZIAD) +$74.00

QTY: 60 Outside Air Ducting [Includes: 4 Inch Insulated Flex X 10 Feet Long] (UZI) +$128.00

QTY: 61 Heatflo Conversion Kit (F3790) +$641.00

QTY: 62 Central Forced Air Kit [Includes: Blower, Flex Adapter, 2 Clamps, Variable Speed Control, Thermo-Disk, Fan to Flexible Pipe Adapter, Backdraft Damper and Aluminium Tape] (BISFWK-1) +$962.00

QTY: 63 Flexible Pipe - 5 Inches X 15 Feet (5FLEX15) +$267.00

QTY: 64 Flexible Pipe - 5 Inches X 25 Feet Long (5FLEX25) +$438.00

QTY: 65 Heating and Cooling Thermostat (HctW) +$534.00

QTY: 66 Owners Manual [Hard Copy] [900992-00] (OMHC-L) +$9.99

QTY: 67 Owners Manual [Electronic Copy] [900992-00] (OMEL-L) +$0.00
QTY:
